The best of SLA meets the best of light projection.

Fast

Dual HD projector-based SLA offers up to 5x faster curing layer times compared to laser-based technology.

Precise

Our high power 7 watt projectors deliver first article success at 90µm pixel resolution, with exceptional print quality and repeatability.

Versatile

Compact size with a large build volume capacity. The perfect tool for service bureau and production applications.

Easy to Install

Passes through a standard doorway and can be set up in a few hours. You only need a standard power outlet to start.

Easy to Change Material

Material changes have never been easier. The PSLA 270 features a mobile cart designed to accommodate a variety of material vat sizes to best fit your application. The vat system is designed to keep the elevator, displacer, and recoater nested with the vat of resin they are used with.

The Material Delivery Module (MDM) is also an integral part of the mobile cart so nothing needs to be cleaned during a material swap. One cart is simply exchanged for another and all the necessary components come with it. Additionally, precision vat location to the frame of the printer ensures the smoothest possible material change.

Projection-based SLA System

The PSLA 270 architecture merges the best of both worlds: the pixel productivity of projection-based technology and the buoyant, non-contact precision of SLA. Its dual high-resolution projectors deliver unmatched pixel efficiency, far surpassing traditional laser systems.

First Article Success & Accuracy

With the PSLA 270 there is no contact, and no gravity-based distortion. The end result is remarkable precision, consistency and part quality irrespective of geometry with a fraction of the support structure needed by other solutions. While building inverted with a membrane works great for small parts, it introduces distortion from peeling and gravity on bulky parts with large cross-sections.

Flexible Design

The doors and the UI can be flipped to allow for the UI to be placed on the right or left of the machine. This enables the most efficient layout for your space and workflow. The compact frame enables the printer to fit through a standard door providing ease of delivery and installation.

The Next-Generation in 3D Printers

A high-resolution printer that merges the speed and production-grade material benefits of Figure 4 light projection technology with the repeatable, high-quality outcomes of SLA.

Tech Specs

• Printable build volume (xyz): 242 x 265 x 300 mm (9.5 x 10.4 x 11.8 in)
• Compact printer footprint
• Projection-based SLA printing using dual 7-watt HD projectors
• Dual-rail recoating system
• Add material to vat with auto-fill resin pump or hand pouring
• Production-grade materials
• Industry-leading 3D Sprint software for file preparation and production
• Cloud connectivity for predictive and prompt service with 3D Connect capability
